Breadcrumb

  1. Home
  2. Floor and Building Plans
Floor Plans (3)

Floor and Building Plans

Regulation 6 of the Fire Safety Regulations 2022 require responsible persons of high-rise residential buildings in England to share up-to-date plans of the building with the fire and rescue service. The plans will be used by operational firefighters during an incident and need to be clear, simple and easy to use.

We provided the following resources to assist in the creation of floor and building plans:

  • An example of what your building plans should look like:
    • Example floor plan
    • Example single-page building plan
  • Guidance note with more information
  • A list of all the symbols you need for your plans can be found here



Share your floor and building plans with us!

Upload your floor plans here
Upload your single-page building plan here


Everything you need to know about floor and building plans



Why do you need copies of the plans?

The plans will be used by operational firefighters during an incident to identify the safest, quickest and most efficient way to fight the fire.



How should hard copies be stored?

The responsible person must provide a copy of the plans inside the premises’ secure information box. The plans should be sized to fit on A3 paper, and printed in colour where necessary, to assist in easy identification of the plan symbols.

At least two copies of each plan should be provided inside the secure information box. Plans should be laminated to make sure they remain usable throughout the course of an incident.

NFCC FIA Code of Practice for Premises Information Boxes



What should a floor plan contain?

Floor plans must show the location of specific equipment as defined by the Regulations.

A plan will need to be prepared for each floor. If the floors are identical, it is permissible to prepare a single plan, but we would prefer a separate plan for each floor so that the individual flat numbers can be easily identified.

Here is an example floor plan:

example floor plan





What should a building plan contain?

A separate single page plan must be provided which shows the building and its immediate surroundings. The building plan will help firefighters to work effectively on arrival.

The full list of information to be provided on the building plan is defined in the Regulations and includes all of the following:

  • the surroundings of the building
  • details of the use of the building, for example for commercial or residential purposes
  • access for fire and rescue appliances
  • the dimensions of the building
  • information on the number of storeys of the building and the number of basement levels (if any)
  • information about any maisonettes or scissor section flats
  • inlets for dry-rising mains
  • inlets for wet-rising mains
  • the location of shut-off controls for any sprinklers
  • access points for the building
  • the location of the secure information box
  • the location of the controls for any smoke control system
  • the location of any firefighting shaft
  • the location of main stairways in the building
  • the location of the controls for any evacuation alert system

Here is an example building plan:

Example building plan


Filing cabinets - all grey with one red one open
Need further guidance?
For more information on the preparation and storage of plans, including examples of floor and building plans, please refer to The Code of Practice for the Provision of Premises Information Boxes in Residential Buildings.
NFCC Code of Practice

Read more

The Fire Safety (England) Regulations 2022

High-Rise 003
Back
Go back to the main page for The Fire Safety (England) Regulations 2022
